In this technical guide, we'll explore the practical steps to fortify your Scalable Kubernetes Service (SKS) workloads on Exoscale using Velero, a robust backup and restore tool.
The guide includes a hands-on demo, illustrating how Velero simplifies the backup and recovery process for stateful applications like Nextcloud.
Whether you're a seasoned DevOps professional or diving into Kubernetes for the first time, this guide is tailored to enhance your understanding of backup strategies, ensuring the resilience of your SKS workloads.
Follow the guide for K8s Cluster Installation and Configuration on Exoscale SKS.
Step 2: Deploy Longhorn for Persistent Storage
Integrating Longhorn into the SKS cluster enhances data management, resilience, and backup capabilities, providing a reliable storage solution for stateful applications running in Kubernetes.
kubectl apply -f https://raw.githubusercontent.com/longhorn/longhorn/master/deploy/longhorn.yaml
Check that all the pods are in the Running state
kubectl -n longhorn-system get pods
kubectl port-forward deployment/longhorn-ui 7000:8000 -n longhorn-system
Access the Longhorn UI at http://127.0.0.1:7000/#/.
Step 3: Deploy Stateful Application (e.g., Nextcloud)
For the demo we're going to use the Nextcloud application, which is simple to deploy and allows us to work easily with persistent data. And what's more, I love this soft!
helm repo add nextcloud https://nextcloud.github.io/helm/
helm repo update
kubectl create ns nextcloud && helm -n nextcloud install nextcloud nextcloud/nextcloud --set service.type=LoadBalancer,persistence.enabled=true,nextcloud.password=whatanamaizingpassword
Step 4: Install Velero CLI
To perform backup and restore operations directly from your console, you'll need to install and use the Velero CLI.
wget https://github.com/vmware-tanzu/velero/releases/download/v1.12.1/velero-v1.12.1-linux-amd64.tar.gz
tar -xvf velero-v1.12.1-linux-amd64.tar.gz
sudo cp velero-v1.12.1-linux-amd64/velero /usr/local/bin/
rm -rf velero-v1.12.1*
velero version
Step 5: Install Velero using Helm Chart
Now we deploy Velero on the cluster using the official Helm chart.
The latest Velero documentation at this time is https://velero.io/docs/v1.12/
You can find more information about the Helm chart and all the available values on https://artifacthub.io/packages/helm/vmware-tanzu/velero
The settings below will allow us to push the data to the Exoscale s3 service named SOS (Simple Object Storage). The SOS bucket is named veleroexo and hosted in the ch-gva-2 region.
You will need to create an IAM API Keys with a role that allow access to Object Storage service.
Velero has to be initialized with the plugin velero-plugin-for-aws to interact with S3 services and velero-plugin-for-csi for storage operations.
helm repo add velero https://vmware-tanzu.github.io/helm-charts/
[default]
aws_access_key_id=********************************
aws_secret_access_key=**********************************
helm install velero velero/velero \
--namespace velero \
--create-namespace \
--set-file credentials.secretContents.cloud=/home/username/.aws/velero_exo_creds \
--set configuration.backupStorageLocation[0].name=exoscale \
--set configuration.backupStorageLocation[0].provider=aws \
--set configuration.backupStorageLocation[0].bucket=veleroexo \
--set configuration.backupStorageLocation[0].config.region=ch-gva-2 \
--set configuration.backupStorageLocation[0].config.publicUrl=https://sos-ch-gva-2.exo.io \
--set configuration.backupStorageLocation[0].config.s3ForcePathStyle=true \
--set configuration.backupStorageLocation[0].config.s3Url=https://sos-ch-gva-2.exo.io \
--set configuration.volumeSnapshotLocation[0].name=exoscale \
--set configuration.volumeSnapshotLocation[0].provider=aws \
--set configuration.volumeSnapshotLocation[0].config.region=sos-ch-gva-2.exo.io \
--set image.pullPolicy=IfNotPresent \
--set initContainers[0].name=velero-plugin-for-aws \
--set initContainers[0].image=velero/velero-plugin-for-aws:v1.7.1 \
--set initContainers[0].volumeMounts[0].mountPath=/target \
--set initContainers[0].volumeMounts[0].name=plugins \
--set configuration.features=EnableCSI \
--set initContainers[1].name=velero-plugin-for-csi \
--set initContainers[1].image=velero/velero-plugin-for-csi:v0.6.1 \
--set initContainers[1].volumeMounts[0].mountPath=/target \
--set initContainers[1].volumeMounts[0].name=plugins \
--set deployNodeAgent=true
kubectl label volumesnapshotclasses.snapshot.storage.k8s.io longhorn velero.io/csi-volumesnapshot-class=true
velero backup-location set exoscale --default
Check that everything is up and running
kubectl -n velero get all
velero get backup-locations
Step 6: Functional Demo
Let's add some data in Nextcloud before the backup and restore operations. Log to the Nextcloud UI with the admin account and the password provided during the installation.
kubectl port-forward deployment/nextcloud 8099:80 -n nextcloud
Access the Nextcloud UI at http://127.0.0.1:8099/apps/files/?dir=/Documents and add some files.
Now we create a backup of all the elements of the nextcloud namespace.
velero backup create nc-backup-10112023-4 --include-namespaces nextcloud
The backup operation will be executed in the background. You can describe the backup operation or follow the backup logs. Velero will give you the command to get the information.
If you describe the backup operation you can see the status of the operation, or which namespace and resources are included.
velero backup describe nc-backup-10112023-4 --details
Get the status of the backup using Velero CLI. You can also see the backup expiration date and the storage location.
velero get backup
Delete the entire Nextcloud namespace
kubectl delete ns nextcloud
Validate that the nextcloud PV is deleted to be sure that the restore process is fully fonctionnal.
kubectl get pv
Now we start the restore process using the Velero CLI
velero restore create --from-backup nc-backup-10112023-4
The restore process will execute in background. Again Velero will give you the command to get information about the status of the operation.
velero restore describe nc-backup-10112023-4-20231110074848 --details
You get also get the status of the restore operation.
velero restore get
Validate that Velero as recreated all the resources in the nextcloud namespace.
kubectl -n nextcloud get pvc
kubectl -n nextcloud get pv
kubectl -n nextcloud get pods -w
Access the Nextcloud UI at http://127.0.0.1:8099/apps/files/?dir=/Documents and validate that your files are present.
kubectl port-forward deployment/nextcloud 8099:80 -n nextcloud
All these operations can be carried out using the CRDs provided by Velero.
Now armed with these tools and insights, you're ready to navigate the dynamic seas of Kubernetes Backups with confidence. Happy deploying! 🚀🔒
